Vendor code: 2H08
Hydraulic heel height adapter 2H08
activity level · maximum user weight
Short answer: Adapter installed above the foot that smoothly adjusts the heel height of the prosthesis from 0 to 40 mm. For people who switch between shoes with different heel heights, up to 100 kg.
- Maximum user weight
- 100 kg
- Heel adjustment
- 0 to 40 mm
- Build height
- 75 mm
- Weight
- 360 g
Indication
Users up to 100 kg, with activity level 1 to 3, who wear shoes with different heel heights.
Features
- Smooth heel height adjustment, without redoing the prosthesis alignment at every shoe change.
Technical data
| Maximum user weight | 100 kg |
|---|---|
| Activity level | 1 to 3 (METIZ scale) |
| Heel height adjustment | 0 to 40 mm |
| Angular adjustment | up to 7.5° |
| Compatible foot sizes | 22 to 30 |
| Build height | 75 mm |
| Weight | 360 g |
| Temperature range | −25 to +40 °C |
| Service life | 3 years |
Frequently asked questions
Who can prescribe this component?
The prosthetist, after assessing the amputation level, weight, routine and mobility level of the user. Metiz Brasil does not sell directly to patients.
How do I buy for my workshop or clinic?
Through authorized distributors or directly from the Metiz Brasil sales team, by WhatsApp or by the e-mail on the contact page.
Is there a warranty?
Yes. The term varies by component and is stated at purchase by the Metiz Brasil team.
Sources
Technical data from the data sheets published by the manufacturer, checked in October 2026. If there is any difference, the documentation supplied with the product prevails.
