Carbon foot 1H20Y / 1H21Y, manufacturer's video
Manufacturer's video, METIZ channel · YouTube, in Portuguese
Vendor code: 1H20Y
Carbon fiber foot 1H20Y / 1H21Y
M1M2M380kg100kg125kg
activity level · maximum user weight
Short answer: Carbon foot with a front elastic element of non-linear stiffness, in categories chosen by weight, from 45 to 125 kg. The 1H20Y has the standard cover and the 1H21Y has a narrow cover, designed for women's footwear.
- User weight range
- 45 to 125 kg
- Mobility
- M1 to M3
- Build height
- 70 to 77 mm
- Heel height
- 10 mm
Indication
Transfemoral amputation at all levels, transtibial in the upper, middle and lower thirds, and prostheses after knee or hip disarticulation. Activity level M1 to M3.
Features
- Improved cushioning at forefoot push-off, with easy, smooth roll-over.
- Front elastic element that returns energy in proportion to the pace of the gait.
- More stability in the stance phase.
Technical data
| User weight range | 45 to 125 kg |
|---|---|
| Activity level | M1 to M3 |
| Versions | 1H21Y (narrow cover), sizes 22 to 25; 1H20Y (standard cover), sizes 24 to 28 |
| Build height | 77 ±2 mm (1H21Y, 22 to 23) and 70 ±2 mm (24 to 25) |
| Heel height | 10 mm |
| Foot without cover | 2H21 or 2H20 |
| Cosmetic cover | 9H21 or 9H20 |
| Sides | right and left |
Maximum weight by stiffness category
The stiffness category is chosen by the user's weight. Maximum values from the manufacturer's data sheet; the dot means the category does not exist for that size.
| Category | 1H21Y, size 22 to 23 | 1H21Y and 1H20Y, size 24 to 25 | 1H20Y, size 26 to 28 |
|---|---|---|---|
| 1 | 60 kg | · | · |
| 2 | 65 kg | 70 kg | 70 kg |
| 3 | 80 kg | 80 kg | 80 kg |
| 4 | 100 kg | 90 kg | 90 kg |
| 5 | · | 110 kg | 110 kg |
| 6 | · | · | 125 kg |
The table follows the manufacturer's datasheet, which publishes 6 stiffness categories for this line.
Videos
Frequently asked questions
Who can prescribe this component?
The prosthetist, after assessing the amputation level, weight, routine and mobility level of the user. Metiz Brasil does not sell directly to patients.
How do I buy for my workshop or clinic?
Through authorized distributors or directly from the Metiz Brasil sales team, by WhatsApp or by the e-mail on the contact page.
Is there a warranty?
Yes. The term varies by component and is stated at purchase by the Metiz Brasil team.
Sources
Technical data from the data sheets published by the manufacturer, checked in October 2026. If there is any difference, the documentation supplied with the product prevails.
